Vrecko na prach z tekutiny
  • Vrecko na prach z tekutiny Vrecko na prach z tekutiny
  • Vrecko na prach z tekutiny Vrecko na prach z tekutiny
  • Vrecko na prach z tekutiny Vrecko na prach z tekutiny

Vrecko na prach z tekutiny

Vysoko kvalitný kvapalinový vrecko na kvapalinové lôžko Qingdao Star Machine je rozhodujúcou súčasťou procesu sušenia a granulácie. Zvyčajne je vyrobený z tkaného polyesteru alebo polyesterovej hodvábnej handričky a ošetrená technológiou šitia a tesnenia, aby sa zaistil hladký a rovný povrch. Vrecko na prach z kvapaliny ponúka nízku odolnosť, dobrú priepustnosť vzduchu a dokáže odolávať priľnavosti, vďaka čomu je účinný pri zachytávaní prášku. Na základe vašich potrieb môžeme vytvárať vlastné veľkosti, ako napríklad 16, 18 alebo 24 prstov. Prípadne môžeme produkovať podľa vašich poskytnutých vzoriek.

Odoslať dopyt

Popis produktu

Product Role

1. Drug powder should be filtered by Fluid Bed Dust Bags to prevent it from dispersing into the exhaust system.

2. The Fluid Bed Dust Bags used should have low resistance and high efficiency to ensure a good bed pressure drop. This will help achieve a good ventilation heat exchange rate, improve drying efficiency, and reduce energy consumption.

3. The granulation effect is affected by the uniformity of the pore size of the Fluid Bed Dust Bags (3μm, 5μm, 10μm). The higher the uniformity, the better the internal quality uniformity of the particles. After granulation of micronized raw materials, the uneven pore size of the Fluid Bed Dust Bags can result in decreased or uneven content.

4. The antistatic ability and welding seam technology of the Fluid Bed Dust Bags directly affect the anti-adhesion force, which in turn affects the product yield. For example, in the FBD200 fluidized bed, a general Fluid Bed Dust Bags causes each batch of powder to agglomerate and adhere, resulting in a loss of about 1.5-2.0kg. Based on the production calculation of 2 batches per day and 180 days (life of the Fluid Bed Dust Bags ), the material loss can be up to 360kg. Choosing high-quality Fluid Bed Dust Bags can effectively reduce losses, energy consumption, and costs, while increasing yields. Therefore, the Fluid Bed Dust Bags is an excellent choice, and we look forward to working with you to improve the level of fluidized bed drying and granulation technology.

Fluid Bed Dust Bag


Main Parameter

project numerical value unit
Material POLYESTER
Weight 180-200 g/㎡
thickness 0.26-0.28 mm
Breathability 80-120 mm/s
conductive thread Knitted black silk (striped style)
Conductive wire spacing 5.0 mm
surface resistance 10/6/9/6/3/6/0 Ω
organizational structure Sparse weave (100×300D)/filament
Longitudinal breaking strength ≥1000 N/5cm
Transverse breaking strength ≥1300 N/5cm
Operating temperature <130
Chemical compatibility Resistant to weak acids, weak bases, solvents, and active oxidants
surface form Glossy
Precautions Moisture-proof, avoid strong light exposure

The table is for reference only, we support OEM, ODM.
